G2 is our one compact aluminum ribbon
tweeter. It is perfect for use in two-way systems design
or more than two-way systems design, and also can be
used as a super tweeter to make up the defect of high
frequency in loudspeaker system.
|
| Technical
data(Patent No.ZL98 2 46922.5) |
- Rated impedance: 8¦¸
- Rated power: 40W
- Sensitivity: 96dB/W/M
- Frequency range: 1700Hz£40KHz¡À3dB
- Ribbon dimension (mm): 8.5W¡Á70L¡Á0.01T
- Ribbon shape: wave
- Magnet: magnet shielded
- Recommended frequency cut: above 2500Hz
- External dimension (mm): 74W¡Á120H¡Á90D
- Weight: 1.15Kg/pc
|
