| F SERIES | W2-800SJ |
|
| ||||
| DIAPHRAGM MTL | Doped Alum | ||||
| SURROUND MTL | TPR | ||||
| NOMINAL IMPEDANCE | 4 W | ||||
| DCR IMPEDANCE | 3.5 W | ||||
| SENSITIVITY 1W/1m | 87 dB | ||||
| FREQUENCY RESPONSE | 160-20K Hz | ||||
| FREE AIR RESONANCE | 160 Hz | ||||
| VOICE COIL DIAMETER | 25.4 mm | ||||
| AIR GAP HEIGHT | 3 mm | ||||
| RATED POWER INPUT | 10 W | ||||
| MAXIMUM POWER INPUT | 20 W | ||||
| FORCE FACTOR, BL | 3.70 TM | ||||
| MAGNET WEIGHT ( oz) | Neodymium | ||||
| MOVING MASS | 1 g | ||||
| FERRO FLUID ENHANCED | No | ||||
| SUSPENSION COMPL. | 959 MN-1 | ||||
| EFFEC.PISTON AREA | 0.0013 M2 | ||||
| Levc | 0.04 mH | ||||
| Zo | 39.85 ohm | ||||
| X-max | 1 mm | ||||
| Vas | 0.19 Litr. | ||||
| Qts | 0.23 | ||||
| Qms | 2.67 | ||||
| Qes | 0.26 | ||||
 |
