F SERIES W2-802SE

  • FULL RANGE DESIGN
  • ABS BASKET, MAGNETICALLY SHIELDED
  • PP CONE WITH R SHAPE TPR SURROUND
  • NEODYNIUM MAGNET DESIGN
  • GOOD FOR CAR, HOME THEATER, MULTIMEDIA APPLICATION
  • SPECIAL ALUMINUM PHASE PLUG TO PROVIDE WIDER DISPERSION AND HEAT SINK





 2" POLYCONE  FULL RANGE
DIAPHRAGM MTL PPM
SURROUND MTL TPR
NOMINAL IMPEDANCE 8 W
DCR IMPEDANCE 6 W
SENSITIVITY 1W/1m 86 dB
FREQUENCY RESPONSE 160-20K Hz
FREE AIR RESONANCE 160 Hz
VOICE COIL DIAMETER 20.4 mm
AIR GAP HEIGHT 3 mm
RATED POWER INPUT 8 W
MAXIMUM POWER INPUT 16 W
FORCE FACTOR, BL 3.58 TM
MAGNET WEIGHT    ( oz) Neodymium
MOVING MASS 1 g
FERRO FLUID ENHANCED No
SUSPENSION COMPL. 1487 uMN-1
EFFEC.PISTON AREA 0.0013 M2
Levc 0.037 mH
Zo 66 ohm
X-max 1 mm
Vas 0.36 Litr.
Qts 0.33
Qms 3.53
Qes 0.36
