| FSERIES | W4-655SA |
 |
 |
 |
|
| ||||
| DIAPHRAGM MTL | Paper | ||||
| SURROUND MTL | Rubber | ||||
| NOMINAL IMPEDANCE | 8 W | ||||
| DCR IMPEDANCE | 6 W | ||||
| SENSITIVITY 1W/1m | 89 dB | ||||
| FREQUENCY RESPONSE | 70-14k Hz | ||||
| FREE AIR RESONANCE | 70 Hz | ||||
| VOICE COIL DIAMETER | 25 mm | ||||
| AIR GAP HEIGHT | 6 mm | ||||
| RATED POWER INPUT | 40 W | ||||
| MAXIMUM POWER INPUT | 80 W | ||||
| FORCE FACTOR, BL | 5.73 TM | ||||
| MAGNET WEIGHT (11oz) | 305 g | ||||
| MOVING MASS | 4 g | ||||
| FERRO FLUID ENHANCED | No | ||||
| SUSPENSION COMPL. | 1104MN-1 | ||||
| EFFEC.PISTON AREA | 0.0057M2 | ||||
| Levc | 0.4295mH | ||||
| Zo | 79.5971ohm | ||||
| X-max | 3 mm | ||||
| Vas | 5.09 Litr. | ||||
| Qts | 0.33 | ||||
| Qms | 4.35 | ||||
| Qes | 0.35 | ||||
|
